The DCQ-5 handheld static eliminator comes with a built-in static elimination electrode that generates ions via corona discharge. It neutralizes static charges on charged objects with ion airflow, while simultaneously blowing dust off workpiece surfaces. Compact and lightweight for easy handheld operation. Its built-in miniature piezoelectric transformer converts input DC power into high-frequency low-voltage alternating current. Unlike conventional equipment, it requires no high-voltage cable, delivering superior ease of operation.
Lightweight plastic air gun weighing only 280 grams, comfortable to hold and efficient for static elimination
All high-voltage components integrated inside the gun, eliminating high-voltage cables and greatly improving safety
High-frequency low-voltage corona discharge delivers excellent ion balance and high working efficiency
Equipped with piezoelectric transformer to boost low input voltage for corona discharge
Built-in automatic ion balance function
Replaceable discharge needle
Electronics & Electrical Industry: Prevent dust adhesion and contamination on LCD screens, mobile phones and internal components
Assembly Industry: Dust removal and static neutralization for mechanical assembly processes
Plastics Industry: Static elimination and dust cleaning during plastic molding and processing
Item | Parameter |
|---|---|
Model | DCQ-5 |
Input Power | DC24V (with AC adapter compatible with AC100~240V) |
Current Consumption | 0.1A |
High Voltage Power Supply Type | High-frequency high-voltage power supply |
Output Voltage | AC 2.0kV |
Ion Balance | ≤ ±15V |
Supply Air Flow | 89 Nl/min (0.1MPa) ~ 314 Nl/min (0.5MPa) |
Ozone Concentration | ≤ 0.04 ppm |
Ambient Operating Temperature | 0 ~ 40°C |
Compressed Air Pressure Range | 0.05 ~ 0.6 MPa |
Overall Dimensions | 135×140×25mm (Width × Height × Depth) |
Net Weight | 280g |
Alarm Function | Indicator triggers when high-voltage output cuts off |
